Digi 001 Quick Start Guide74
To record Pro Tools LE tracks to an ADAT:
1 Connect the ADAT Optical Out connector on the back of the Digi 001 PCI Card to the
ADAT Optical In connector on the back of the ADAT deck.
2 Open the session you want to record to the ADAT.
3 Record enable up to 8 audio tracks on the ADAT.
4 Pan 4 pairs of tracks so that each pair is panned hard stereo (one track of each pair is
panned all the way left, and the other is panned all the way right).
5 Route each track pair to a separate Optical output pair by selecting from the Output pop-
up menu for each track. For example, if one of your pairs was 3(L)–4(R), you could route
this pair to the output labeled #1/9 Optical 1-#1/10 Optical 2.
6 Start recording on the ADAT, then click Play in the Transport window in Pro Tools LE.
When playback is complete, stop both systems.
AC POWER
OPTICAL
METER BRIDGESYNC
Digital
Input
IN OUT
Digital
Output
to Digi 001 PCI Card
Optical out
to ADAT
Optical in
Alesis ADAT
Digi 001 PCI Card
