DigiGrid IOX - Page 43

43
IOX
XLR connectors
Phase Termination Point
Positive (+) Pin 2
Negative (-) Pin 3
Signal Ground Pin 1
Chassis Ground Case
¼” TRS connectors
Phase Termination Point
Positive (+) Tip
Negative (-) Ring
Signal Ground Sleeve
