DigiGrid IOX - 8 Technical Specifications

42
IOX
8. TECHNICAL SPECIFICATIONS
General
■
1U rack-mounted (standard 19” rack-mount wide, 4U high, 380-mm deep excluding connectors)
■
Supported sample rates: 44.1, 48, 88.2 and 96 kHz (176.4 and 192 kHz will be supported in the future)
■
12 channel mic/line inputs (on XLR/TRS combo)
■
6 channel line outputs
■
Word Clock I/O
■
2 SoundGrid ports (RJ45s)
■
Reset switch
■
4 headphone outputs with analog level knobs; range: O to +15 dB
Analog Inputs specications`
■
Input Impedance:
Mic: 2K5 / Line: 8K0 Ohms
■
Gain Range:
Mic: 0 dB to +52.5 dB in 7.5dB steps / Line: -10 dB to +42.5 dB in 7.5dB steps
Fine control provides further 0dB to 7dB in 0.5dB steps
■
Maximum Input Level:
Mic: +26 dBu / Line: +36 dBu
■
Mic Equivalent Input Noise: > -126 dB (150 Ohm source, gain +59.5 dB)
■
Harmonic Distortion: Typically < 0.01% @ unity gain, -10dB input @ 1 kHz
■
Frequency Response: +/-0.5 dB (20 Hz to 20 kHz)
■
Channel Separation: Better than 90 dB (40 Hz to 15 kHz)
Analog Outputs specications
■
Maximum Output Level: +22 dBu
■
Residual Output Noise: <90 dB (20 Hz to 20 kHz)
■
Frequency Response: +/-0.5 dB (20 Hz to 20 kHz)
■
Output Impedance: 50 Ohms
■
Channel Separation: Better than 90 dB (40 Hz to 15 kHz)
■
Harmonic Distortion: Typically < 0.01% @ -10dB Output @ 1 kHz
