ITEM Descriptions
1 Display method Vacuum fluorescent display
2 Number of character 20 columns x 2 lines
3 Character font 5 x 7 Dot matrix
4 Display color Blue green
5 Brightness 700 cd/ m
6 Fonts
96 alphanumeric
13 kinds of international character sets
1 kind of user define character set
7 Character size 9.03 mm x 5. 25 mm
8 Power supply 5VDC or 9~ 45VDC
9 Power consumption 6 W (Max.)
10 MTBF 30,000 hours (power on time)
11 Panel dimensions 224 (W) x 93 (H) x 50(D) mm
12 External dimensions
Long 225(W) x 100(D) 500(H)mm
Middle 225(W) x 100(D) 281(H)mm
Short 225(W) x 100(D) 193(H)mm
13 Viewing angle (Horizontal) 120 degrees
14 Viewing angle (Vertical) 90 degrees
15 Rotation angle (Horizontal)
350 degrees
16 Tilt angle 0 ~ 60 degrees
17 Weight 1.25 Kg
18 Operating temperature
0 ~ 45
℃
19 Operating Humidity 10%~90%
20 Storage Temperature
-10 ~ 50
℃
21 Storage Humidity 10%~90%
Table 2-1
