Digital-Ally DVM-800 Installation Guide

Digital Ally, Inc. | Installation Instructions
3-12
DVM-800 Installation Guide | 860-00185-00 Rev L
Go Back To Table of Contents
Step 3: GPS Module
Clean the windshield glass with isopropyl alcohol. Plug the GPS Module connector into
the port on the back of the DVM and screw the locking ring down.
Use full length of cable to locate the GPS module away from the DVM in the upper right
or left corner of windshield, outside of the black shaded area.
Do Not mount the GPS Module:
• In the headliner
• Under metal
• Within 1 foot of the Wi-Fi Antenna
Using the included double-sided tape, attach the module to an unobstructed location
on the windshield below the rooine. Do not place the GPS Module near any other
vehicle antenna.
Step 4: Wi-Fi Antenna
Clean the windshield glass with isopropyl alcohol. Plug the Wi-Fi Antenna into the USB
port on the back of the DVM. Using the included double-sided tape, attach the antenna
to an unobstructed location on the windshield below the rooine away from the GPS
Module.
DVM-800
Rear Panel
Wi-Fi Antenna
