DVM-800 Installation Guide | 860-00185-00 Rev L
Go Back To Table of Contents
Date: Installer:
Vehicle #: Make, Model, Year:
License Plate: Vehicle Color:
DVM Serial #: VIN Number:
To congure an input sensor, the Administrator must know the signaling of the device.
Measure and record the DC voltages and provide the information to the Administrator.
Vehicle Electrical Data
IF Cable
Wire Color Device Type/Description
Measured DC Voltage
Inactive VDC Active VDC
RED Reverse Gear Signal
(Park) (Reverse)
ORANGE Emergency Lights
BLUE Brakes
YELLOW VSS (Pulse Only) or Congurable
WHITE
Installer to complete upper section
Administrator to complete lower section
Sensor Conguration
Sensor
#
Sensor
Name
Wire
Color Connection
Signal to Input Sensor
Detection Type Threshhold
1 Reverse RED
Reverse Gear
Switch
Low to High Standard
High to Low High
2 Lights ORANGE
DC Output-Light
Bar Controller
Low to High Standard
High to Low High
3 Brakes BLUE
Brake Switch or
3rd Brake Light
Low to High Standard
High to Low High
4
VSS YELLOW VSS
Pulse
Congurable YELLOW Congurable
Low to High Standard
High to Low High
5 Congurable WHITE Congurable
Low to High Standard
High to Low High
6
Wireless
Microphone
GREEN
MIC Trigger from
Green Wire of
DWM Harness
REMOTE
TRIGGER
OUT
BROWN
MIC Trigger from
Brown Wire of
DWM Harness
GROUND BLACK Chassis Ground
Interface Box Sensor Worksheet
