SmartSource Elite Series - Installation & Operations Guide
January 2017 8227 4907-003 Page 13 of 32
Preparing for Document Flow
1. Adjust the floor extender and document limit to match the length of the documents to be fed by sliding
them out, as shown below.
2. For proper feeding, the floor extender should be extended to support the documents in the feed
hopper and prevent them from tipping or skewing.
3. The document limit should be set so that the document can fit easily in the pocket. If feeding
documents of different lengths, set the document limit to match the longest document.
Document / card preparation
The SmartSource Elite is optimized to work with the majority of normal financial documents. However, the
unit will function acceptably with a wide range of paper weights and thicknesses, from thicker tab-cards to
thin multipart form stock, as well as specialty items like ATM envelopes.
If you process such documents, you may notice minor degradations in performance, such as reduced
output pocket capacity, degraded stop rate, or increased noise while running.
1. For trouble-free operation, documents and cards should be clean, dry and free of attached objects
such as staples, paper clips, sticky tape or rubber bands.
2. Smooth out creases, folds and dog-eared corners.
a. Creased and folded documents may cause shadows or other defects in document
images.
Hopper extender moved out to
fully-support documents
Hopper extender moved out to
fully-support documents
Document limit moved out to
accommodate longest documents
