January 2017 8227 4907-003 Page 15 of 32
SmartSource Elite Series - Installation & Operations Guide
If leading edges are not properly aligned, the unit may feed documents out of sequence. If bottom edges
are not aligned, the unit may not be able to read the MICR code line, and document images may be
skewed. When inserting larger numbers of documents, an automated powered document jogger may be
helpful. Suitable joggers are available from the Digital Check Store www.digitalcheck.com, part numbers
750606909, 752008995 and 752010901.
Insert documents into the feed hopper as shown. On Professional Elite and Ultraviolet Elite units, the feed
hopper will open automatically. On Merchant Elite units, the feed hopper will need to be opened manually
by pushing back the grey flag, as shown above.
Processing documents
When documents are placed in the feed hopper, the unit may begin processing automatically, or you may
need to press the start-stop button briefly to start processing. How this works depends on your document
processing software application. Documents will be fed singly from the feed hopper and stacked in the
output pocket. The unit will stop automatically when the feed hopper is empty. To continue processing,
place more documents in the feed hopper. Depending upon your application, the unit may resume
processing automatically, or you may need to press the start-stop button again to resume.
Documents not properly aligned
for trouble-free feeding
Documents properly aligned for
trouble-free feeding
