The keypad is illuminated for operation in dark environments. Available
functions are illuminated in yellow while selected (active) functions are
illuminated in green. Functions that are not available are not illuminated.
In addition to the various functions, 10 keys are numbered 0-9. These
keys are used for PIN code and other numeric functions as applicable.
POWER
Switches the projector between on and standby modes. Press firmly
(1 sec) to switch on. Press firmly (1 sec) twice to switch off.
ARROW KEYS
Use the arrow keys to control lens and LCD functions.
LCD
Enable the backlight in the LCD.
TEST
Applies test images for set up and adjustment.
RESET
Press and hold for 2 seconds to reset settings to factory default.
ZOOM
Select ZOOM, then use arrow keys to zoom in or out.
FOCUS
Select FOCUS, then arrow keys to focus the image
SHIFT
Select SHIFT, then the arrow keys to shift the image up, down or
sideways.
IRIS
Select IRIS, then arrow keys to adjust to desired combination of
brightness and contrast.
KEYPAD
