TECHNICAL DATA
PROJECTOR UNIT
Resolution 1920 x 1080, 16:9 aspect ratio
Display technology Single chip DLP™ technology by Texas Instruments®
DMD™ with DarkChip™ technology
Compatibility 1080p
Brightness HD 1080
2500 ANSI lumen (typ), 2000 ANSI lumen (min) @ 2x250W lamp power*)
2000 ANSI lumen (typ), 1600 ANSI lumen (min) @ ECO-mode 2x200W lamp power*)
3500 ANSI lumen (typ), 2800 ANSI lumen (min) @ 2x300W lamp power*)
2800 ANSI lumen (typ), 2200 ANSI lumen (min) @ ECO-mode 2x240W lamp power*)
*) Initial brightness.
Contrast 7500 : 1 B/W (max) at max IRIS, 1000 : 1 B/W (min) at min IRIS
Lamp 2x250W UHP™ dimmable to 2x200W
2x300W UHP™ dimmable to 2x240W
Lamp Life 2000 hrs (typ) to 50% brightness @ 250W (250W lamp)
4000 hrs (typ) to 50% brightness @ 200W (250W lamp)
1700 hrs (typ) to 50% brightness @ 300W (300W lamp)
2200 hrs (typ) to 50% brightness @ 240W (300W lamp)
Sound Pressure Level Lp = 36 dB(A)/20mPa (typ), 45 dB(A)/20mPa (max) @ 20°C/68°F, sea level
Dimensions 400 x 500 x 200 mm / 15.7” x 19.7” x 7.9”, excluding lens
Weight 12.6 kg / 27.8 lbs, excluding lens
Inputs 1 DVI-D female digital RGB
1 RS 232 9 pin female DSUB (control, firmware update)
1 USB-B female (control, firmware update)
1 LAN RJ-45 female (control, firmware update)
1 Remote Control 3.5 mm female stereo jack
Outputs 2 Trigger 3.5 mm female stereo jack, 12 V @ 80 mA Max
1 RS 232 9 pin male DSUB
Power 90-260 VAC, 50-60 Hz, 840W @ 2x250W
940W @ 2x300W
Energy dissipation 2866BTU/h @ 2x250W
3200BTU/h @ 2x300W
MTBF 17500 hrs
Conformance CE, FCC A, CSA(C,US)
Temperature operating 0-40°C / 32-104°F, 0-1500 m / 0-4950 ft
0-35°C / 32-95°F, 1500-3000 m / 4950-9900 ft
Temperature storage -20 - 60°C / -4 - 140°F
Humidity operating 20-90% RH, non-condensing
Humidity storage 10-95% RH, non-condensing
28
