20
english
21
A
B
CEILING MOUNT COVER
The auxiliary cable cover can be mounted on the projector to
conceal the interface cables and power cord when the unit is
ceiling mounted.
Connect all cables and fix them in place before the cable cover
is attached to the projector.
A Attach the cable cover to the projector by inserting the
horisontal hooks on the cover in the horisontal
slots on the rear of the projector.
B Turn the cover untill the vertical hooks on the
cover are inserted into the vertical slots on the rear of the
projector.
C The cover will snap in place, to release pull the
vertical hooks on the cover out of the slots, letting the cover
hinge on the horisontal hooks.
CEILING MOUNT
