Digital Projection E-Vision Laser 7500 Series - Formats

page 93
Digital Projection E-Vision Laser 7500 & 8500 Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev B September 2016
Standard
Resolution
Horizontal
Frequency (kHz)
Frame Rate (Hz)
PCLK (MHz)
Component /
5BNC
VGA - RGBHV
5BNC - RGBHV
DisplayPort /
DVI-D
HDMI / HD-BaseT
HD/SDI/3G
Remark
RGB
YUV 8-bit
YUV 10-bit YUV 12-bit
HDTV
(continued)
1080p 67.433 59.94 148.352 X X X X X X X X X
1080p 67.5 60 148.500 X X X X X X X X X
PsF formats 1080sf 33.75 30 74.250 X
1080sf 28.125 25 74.250
3D formats
Standard
Resolution
V-Freq
(Hz)
V-Total
H-Freq
(kHz)
HDMI1/2
DisplayPort /
DVI-D
HB
Dual-pipe HDMI
(*1)
HB
DisplayPort
(*1)
Remarks
720p50 Frame Packing 1280x720 50.00 1470 37.50
ü
*3
720p59 Frame Packing 1280x720 59.94 1470 44.96
ü
*3
720p60 Frame Packing 1280x720 60.00 1470 45.00
ü
*3
720p50 Top-and-Bottom 1280x720 50.00 750 37.50
ü ü
*3
720p59 Top-and-Bottom 1280x720 59.94 750 44.96
ü ü
*3
720p60 Top-and-Bottom 1280x720 60.00 750 45.00
ü ü
*3
1080p23 Frame Packing 1920x1080 23.98 2205 26.97
ü
1080p24 Frame Packing 1920x1080 24.00 2205 27.00
ü
1080i50 Side-by-Side (Half) 1920x1080 50.00 1125 56.25
ü ü
*3
1080i59 Side-by-Side (Half) 1920x1080 59.94 1125 67.43
ü ü
*3
1080i60 Side-by-Side (Half) 1920x1080 60.00 1125 67.50
ü ü
*3
Notes
Remarks:
*1: HB(High Bandwidth) mode
without warping/blending.
*2: 8-bit / color.
*3: Frame drop at scaler and frame
doubling at formatter. Sources
greater than 60 fps are processed
at half the frame rate, then frame
doubled.
