Digital Projection E-Vision Laser 7500 Series - 2:3:3:2 (Advanced) Pulldown

page 89
Digital Projection E-Vision Laser 7500 & 8500 Series
Reference Guide
FRAME RATES AND PULLDOWNS EXPLAINED
Rev B September 2016
2:3:3:2 (advanced) pulldown
This method is very similar to the normal pulldown. Unlike the normal pulldown method, the resulting 30 fps video sequence contains only one
frame containing elds from two different source frames.
The advantage of this method is that it is easier to reverse, if necessary.
Original lm,
24 fps
Field 1 (odd) Field 2 (even) Resulting video,
30 fps
Notes
The projector will use advanced
pulldown on suitable video material,
wherever possible.
