Digital Projection E-Vision Laser 7500 & 8500 Series
Operating Guide
USING THE PROJECTOR
Rev B September 2016
3D menu
Use this menu to enable, disable and set up 3D input, as follows:
• 3D Format — Off, Auto, Side by Side (Half), Top and Bottom, Dual Pipe and
Frame Sequential.
• DLP Link — Off / On.
DLP Link On emits a sync pulse for the 3D glasses via the projected image.
DLP Link Off will send the sync pulse to the sync out connector to use with an
external third party emitter.
• Eye Swap — Normal and Reverse (set to Reverse if the left- and right-eye images
are displayed in the wrong order)
• Dark Time — 0.65 ms, 1.3 ms and 1.95 ms. Set to reduce the effect of images
overlapping while the glasses are switching.
3D Sync
• Offset — use the LEFT and RIGHT arrow buttons to compensate for signal
processing delays in the projector.
• Reference— External, Internal and Auto.
Notes
For further information about
supported 3D formats, see 3D
connections in the Connection
Guide.
If 3D Format is set to Off, all other
3D settings will be unavailable.
Some settings may be unavailable
depending on other settings. For
more information, see Possible
Combinations Of Settings further
in this guide.
Frame Sequential is supported on
the HDMI, DVI-D and DisplayPort
inputs only.
3D video is only possible on the
HDMI, HDBaseT, DisplayPort and
DVI inputs.
The Frame Packing format is
automatically detected by the
projector.
See also 3D types and Some 3D
settings explained further in this
guide.
3D
DLP Link
Eye Swap
3D Format
Dark Time
Off
Normal
Auto
1.95 ms
Reference
Offset
Internal
100
3D Sync
