Digital Projection E-Vision Laser 7500 & 8500 Series
Reference Guide
APPENDIX A: LENS PART NUMBERS
Rev B September 2016
Appendix A: Lens Part Numbers
Throw ratios Part number Focus range Lens shift Lens extension
0.38 : 1 xed (UST) 117-341 0.82 m - 2.71 m none 292.5 mm
0.75 - 0.93 : 1 zoom 115-339 1.02 m - 12.7 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
59.4 mm
0.76 : 1 xed 112-499 0.81 m - 5.08 m none 30 mm
1.25 - 1.79 : 1 zoom 112-500 1.33 m - 11.73 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
36.5 mm
1.72 - 2.27 : 1 zoom 112-501 1.83 m - 14.9 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
10.8 mm
2.22 - 3.67 : 1 zoom 112-502 2.36 m - 24.2 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
29.9 mm
3.58 - 5.38 : 1 zoom 112-503 3.8 m - 35.35 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
46.7 mm
5.31 - 8.26 : 1 zoom 112-504 5.59 m - 54.8 m V: 0.5 (U) 0 (D) frame
H: 0.1 (L) 0.1 (R) frame
87.3 mm
Notes
Throw distance calculations are
based on the distance from the outer
end of the lens, which will vary from
lens to lens.
The 0.38 : 1 xed lens has no
adjustable shift value. However,
the lens has an inherent offset
depending on image size. See
the UST documentation published
separately on the Digital Projection
website.f
