DS6 User Manual
1. HARDWARE / DS6 System Specifications
DS6 SYSTEM SPECIFICATIONS:
Light source: RGBW LED
Beam angle: 20 degrees without diffusion
Maximum LED modules per PSU: 6
Remote control options: Wired (RDM/DMX), Wireless (Art-Net)*
Operating temperature range: 0ºF ~ 115ºF/-20ºC ~ 45ºC
Input power: 90-260 VAC (Worldwide) 50/60 Hz
Cables from PSU to LED module: 32.8' / 10 m
Maximum power draw per DS6 PSU: 600 watts
Dimensions of a single light module: 34" x 22"/87 x 55 cm, 33.5lb/15.2kg
Dimensions of the flightcase (shipping): 45" x 24" x 10"/110 x 60 x 27 cm 99lb/45kg
*Dependant of the communication handle used.
