DigiTech BP-8 Valve - Technical Specifications

Specifications
A/D Converter: 20 bit 128x Oversampled
D/A Converter: 20 bit 128x Oversampled
Sampling Frequency: 39 kHz
DSP Section:
Architecture: Static-Dynamic Instruction Set Computer (S-DISC II™)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 256k x 24 bits (3.5 seconds)
Static Delay Memory: 256 24-bit registers (6.55 milliseconds)
Data ALU Processing: 10.0 MIPS
Address ALU Processing: 15.0 MIPS
Multiplier Size: 24 bits x 24 bits
Tube Type:
(1) 12AX7
Plate Voltage: 100volts
Input Section:
Connector: 1/4” Unbalanced TRS
Nominal Level: -8 dBu
Maximum Level: +10 dBu
Impedance: 470 kohms
Output Section:
Connector: 1/4” TRS
Nominal Level: +4 dBu
Maximum Level: +18 dBu
Impedance: 50 ohms
General:
Frequency Response: 20 Hz. - 16 kHz
S/N ratio: Greater than 95 dB; ref = max signal, 22 kHz measurement bandwidth
Total Harmonic Distortion: Less than 0.04% (1 kHz.)
Memory Capacity: Factory: 40 Programs User: 40 Programs
Power Requirements:
US and Canada: 120 V AC, 60 Hz
Japan: 100 V AC, 50/60 Hz
Europe: 230 V AC, 50 Hz
UK: 240 V AC, 50 Hz
Power Consumption: 16 watts
Dimensions: Length 18” Width 8.75” Height 2.75”
Power Supply: PS-0920
