DigiTech JAMMAN STEREO User Manual

61
Left(Mono)/Right/Rhythm Outputs
Connector Type: 1/4” Unbalanced (Tip-Sleeve)/Balanced
(Tip-Ring-Sleeve)
Output Impedance: 100 Ω Unbalanced/ 200 Ω Balanced
Maximum Output Level: 10 dBu DFS
Playback Unity Gain: Loop Level knob set to 12 o’clock position
Headphone Output:
Connector Type: 1/8” Stereo (Tip-Ring-Sleeve)
Output Power: 87.5 mW per channel at 50 Ω
Line Inputs to Outputs
Dynamic Range: 105 dB A-weighted (at unity gain)
Frequency Response: +0/-3 dB 20-20 kHz
Voltage Rails +/-14 V
General
Power: < 9 Watts
Current Draw: < 1 A
Adaptor: PS0913B (Included), Output 9 VAC 1.3 A
US and Canada: PS0913B – 120
Japan: PS0913B – 100
Europe: PS0913B – 230
UK: PS0913B – 240
Dimensions: 6.84” (L) x 6.70” (W) x 2.89” (H)
173.6 mm (L) x 170.1 mm (W) x 73.4 mm (H)
Weight: 2.22 lbs, 1.01 kg
DigiTech® engineers are constantly working to improve the quality of our products.
Specifications are therefore subject to change without notice.
Specifications

DigiTech JAMMAN STEREO Specifications

General

Type	-
Bit rate	24 bit
Proper use	DJ
Sample rate	44.1 kHz
Product color	Blue
Power consumption (typical)	9 W

Weight and Dimensions

Depth	173.73 mm
Width	170.18 mm
Height	73.4 mm
Weight	1006 g
