DigiTech JAMMAN STEREO User Manual

60
Digital
A/D/A Conversion: 24-bit
Sampling Frequency: 44.1 kHz
Loop File Format: 44.1 kHz, 16-bit (stereo), uncompressed
WAV file
USB: 2.0 High Speed (USB 1.1 compatible)
Connector Type: 4-pin Type B
Max. Individual Loop Time: 10 minutes
Internal Memory Capacity: Over 35 minutes total loop time (up to
99 loops total)
External Memory Type: SD/SDHC up to 32GB (optional)
External Memory Capacity: Over 16 hours (10.6MB/minute) of
recording time, when using 16GB or
larger SDHC card (up to 99 loops total)
Inputs/Outputs
Microphone Input
Connector Type: Female XLR Pin 2 Hot (no phantom power)
Input Impedance: 1 kΩ Balanced
Maximum Gain: 41 dB (150 Ω source)
EIN: -125 dBu A-weighted (max gain, 150 Ω source)
Left(Mono)/Right Inputs
Connector Type: 1/4” Unbalanced (Tip-Sleeve)
Input Impedance: 500 kΩ Mono/1 MΩ Stereo
Unity Gain Input to Output: Inst Level knob set to 12 o’clock position
Max Input Level at Unity: 4 dBu DFS
Maximum Gain: 14.5 dB
Aux Input
Connector Type: 1/8” Stereo (Tip-Ring-Sleeve)
Input Impedance: 20 kΩ
Maximum Input Level: 1 dBu DFS
Footswitch Input
Connector Type: 1/4” Stereo (Tip-Ring-Sleeve), compatible
with optional DigiTech
®
FS3X 3-button
footswitch
Specifications

DigiTech JAMMAN STEREO Specifications

General

Type	-
Bit rate	24 bit
Proper use	DJ
Sample rate	44.1 kHz
Product color	Blue
Power consumption (typical)	9 W

Weight and Dimensions

Depth	173.73 mm
Width	170.18 mm
Height	73.4 mm
Weight	1006 g
