Basic Operation
QC1936 Digital Storage Oscilloscope 36
Measure the time between 90% and 10% of the first falling edge of
the waveform.
Measure the time between the first rising edge and the next falling
edge at the waveform 50% level.
Measure the time between the first falling edge and the next rising
edge at the waveform 50% level.
Measure the first cycle waveform. Positive Duty Cycle is the ratio
between positive pulse width and period.
Measure the first cycle waveform. Negative Duty Cycle is the ratio
between positive pulse width and period.
Measure the highest voltage over the entire waveform.
Measure the lowest voltage over the entire waveform.
Measure the voltage of the 50% level from base to top.
Voltage between Vtop and Vbase of a waveform.
Defined as (Base - Min)/Amp x 100 %, Measured over the entire
waveform.
Defined as (Max - Top)/Amp x 100 %, Measured over the entire
waveform.
Calculate the arithmetic mean voltage over the first cycle in the
waveform.
Defined as (Vmin-Vlow)/Vamp after the waveform falling.
Defined as (Vmin-Vlow)/Vamp before the waveform falling.
The duration of a burst measured over the entire waveform.
The time between the first rising edge of source 1 and the first rising
edge of source 2.
The time between the first falling edge of source 1 and the first
falling edge of source 2.
The time between the first falling edge of source 1 and the last
falling edge of source 2.
The time between the first falling edge of source 1 and the last rising
edge of source 2.
The time between the first rising edge of source 1 and the last falling
edge of source 2.
The time between the first rising edge of source 1 and the last
rising edge of source 2.
The time between the first falling edge of source 1 and the first
rising edge of source 2.
The time between the first rising edge of source 1 and the first
falling edge of source 2.
Do not take any measurement.
