QC1936 Digital Storage Oscilloscope 69
Chapter 5 Specifications
5.1 Technical Specifications
All specifications herein mentioned apply to the QC1936 oscilloscopes. Before checking an
oscilloscope from your seller to see if it complies with these specifications, make sure it meets the
following conditions:
 The oscilloscope must have been operating continuously for twenty minutes under the
specified operating temperature.
 The Do Self Cal operation must be performed through the Utility menu if the operating
temperature changes by more than 5℃.
 The oscilloscope must be within the factory calibration interval.
All specifications are guaranteed unless noted ‘typical’.
Oscilloscope Specifications
Horizontal
Sample Rate Range
1GS/s
Waveform Interpolation
(sin x)/x
Record Length
Maximum 40K samples per single-channel; maximum 20K
samples per dual-channel (4K, 20K optional)
SEC/DIV Range
QC1936
4ns/div to 40s/div, in a 2, 4, 8 sequence
Sample Rate and
Delay Time Accuracy
±50ppm over any ≥1ms time interval
Delta Time Measurement
Accuracy
(Full Bandwidth)
Single-shot, Normal mode
± (1 sample interval +100ppm × reading + 0.6ns)
>16 averages
± (1 sample interval + 100ppm × reading + 0.4ns)
Sample interval = s/div ÷ 200
Position Range
20ns/div to 80μs/div
(-8div × s/div) to 40ms
200μs/div to 40s/div
(-8div × s/div) to 400s
