AP Dynamometer Service Manual
The popular Dillon Model AP dynamometer is a rugged, robust self-con-
tained and portable tension measuring instrument. Introduced in 1977, the
Model AP is the most widely used dynamometer in the field today in count-
less different applications.
The Dillon ProLift mechanical dynamometer supplemented the Dillon Model
AP dynamometer in 2001. Designed with the input of nuclear fuel handlers,
the ProLift satisfies all of the requirements for these ultra-sensitive applica-
tions. The ProLift offers the following enhancements over the Model AP:
• 5:1 Ultimate safety factor in all capacities
• Exclusive material selection
• Rounded pressure bar ends
• Electroless nickel plating
• Non-destructive examination of 100% of pressure bars in all capacities
• Non-destructive examination of 100% of low-capacity shackles and
shackle pins
• Proof-load tested to 150% of capacity
• Anchor shackles in all capacities
Dillon recommends that the ProLift should be the first choice when future
periodic non-destructive examination or proof loading is required.
These dynamometers are available in crane scale versions. These employ
hooks at the lower end, the large 10-inch diameter dial and are shipped in
plywood reinforced crates in all capacities.
In addition, Dillon offers a popular electronic dynamometer family and other
highly rated force measurement products. See www.dillon-force.com for
more information.
The Dillon Mechanical
Dynamometer Family
This service manual contains information needed for maintenance of Dillon
AP Dynamometers. Included in this manual are the following:
• instructions for disassembly and reassembly
• periodic inspection requirements and procedures
• instructions for calibration and zero adjustments
• technical illustrations
Service details for the ProLift dynamometer can be found in the separate
ProLift Dynamometer Service Manual.
About This Manual
