AP Dynamometer Service Manual
T
able 1
Pressure Bar Capacity Identification
Capacity Capacity Length of Bar Letter/Number
Range
Low 500 LB 8.8 in. A
Low 1,000 LB 8.8 in. B
Low 2,000 LB 8.8 in. C
Low 4,000 LB 8.8 in. D
Low 5,000 LB 8.8 in. E
Low 6,000 LB 8.8 in. F
Low 8,000 LB 8.8 in. G
Low 10,000 LB 8.8 in. H
Med 15,000 LB 8.8 in. J
Med 20,000 LB 8.8 in. K
High 30,000 LB 15.1 in. 1
High 40,000 LB 15.1 in. 2
High 50,000 LB 15.1 in. 3
High 100,000 LB 19.0 in. 1
Low 200 KG 22 cm L
Low 500 KG 22 cm M
Low 1000 KG 22 cm N
Low 2000 KG 22 cm P
Low 4000 KG 22 cm Q
Low 5000 KG 22 cm R
Med 10000 KG 22 cm S
High 15000 KG 38 cm 4
High 20000 KG 38 cm 5
High 50000 KG 48 cm 2
Table 2
Recommended Torque Specifications
Screw size Torque*
6-32 UNC 10-12 in-lb
10-32 UNF 70 in-lb
¼-28 UNF 144 in-lb
* ± 5%
Helpful Unit Conversions:
1 lb = 0.4536 kg
1 kg = 2.205 lb
1 in = 2.540 cm
1 cm = 0.3937 in
