64 EDXtreme User Instructions
11.4 Capacity and Resolution
*Model number in parenthesis shows U.S. convention for describing capacities.
† Ultimate overload protection rating.
11.5 EDX PSU Power Supply Specifications
Model* Capacity x Resolution (normal/enhanced) Overload† Construction
EDX–1T (EDX-2.5K) 2,500 lbf x 2/0.5 1,000 kgf x 1/0.2 10,000 N x 10/2 700% Aircraft-quality
2024 aluminum
EDX–2T (EDX-5K) 5,000 lbf x 5/1 2,000 kgf x 2/0.5 20,000 N x 20/5
EDX–5T (EDX-10K) 10,000 lbf x 10/2 5,000 kgf x 5/1 50,000 N x 50/10
EDX–10T (EDX-25K) 25,000 lbf x 20/5 10,000 kgf x 10/2 100,000 N x 100/20 500% Aircraft-quality
E4340 alloy steel
EDX–25T (EDX-55K) 55,000 lbf x 50/10 25,000 kgf x 20/5 250,000 N x 200/50
EDX–50T (EDX-100K) 100,000 lbf x 100/20 50,000 kgf x 50/10 500,000 N x 500/100
EDX–75T (EDX-160K) 160,000 lbf x 100/50 75,000 kgf x 50/20 — 400% Aircraft-quality
E4340 alloy steel
EDX–100T (EDX-220K) 220,000 lbf x 200/50 100,000 kgf x 100/20 —
EDX-150T (EDX-330K) 330,000 lbf x 200/100 150,000 kgf x 100/50 —
EDX-250T (EDX-550K) 550,000 lbf x 500/200 250,000 kgf x 200/50 —
Enclosure Designed for indoor use
Input Voltage 100-240 VAC 50-60Hz, 0.55A
Output Voltage 5 VDC
Operating Temperature -4 F to 158 F (20 to 70 C)
Connector Sealed connector to be used with EDXtreme or Communicator II
Approval CE
