7
Wiring Diagram - 3 Stage Remote
(MOD 0 & A Units)
Power Cord
Heater
Assembly
Thermostat
3-Position
Switch
Light Dimmer Control
Flame Speed Control
Terminal Block
Remote Control
Receiver
