Dimplex PF3033 Service Manual

10 www.dimplex.com
GESTURE ASSY
LINE T4
NEUTRAL T5
NEUTRAL T6
NEUTRAL T7
HEATER T1
MOTOR T2
LINE IN
NEUTRAL
DISPLAY J8
J7 GESTURE
J5 FLAME 1W
J2 FLAME COLOUR
J3 TOP LIGHT
J4 TOP LIGHT
J1 LOG / MEDIA
F1400 MAIN BOARD 3001260100
NTC J11
FAN J10
FAN J9
HEATER ELEMENT
TOP LIGHT ASSY
FLAME LED ASSY
DISPLAY BOARD ASSY
TOP LIGHT ASSY
LED STRIP, RBG
MAIN TO GESTURE HARNESS
FLICKER MOTOR
HEATER ASSEMBLY
ONLY USED ON MEDIA MODELS
LOG / MEDIA JUNCTION BOARD
THERMAL
CUT OUT
THERMAL
CUT OUT
NUMBER OF CONNECTIONS
IS BASED ON TYPE OF FIREBOX
TYPE OF CONNECTIONS
IS BASED ON TYPE OF FIREBOX
WIRING DIAGRAM
GESTURE ASSY
LED STRIP, RBG
MAIN TO GESTURE HARNESS
FLICKER MOTOR
HEATER ASSEMBLY
ONLY USED ON MEDIA MODELS
LOG / MEDIA JUNCTION BOARD
THERMAL
CUT OUT
THERMAL
CUT OUT
NUMBER OF CONNECTIONS
IS BASED ON TYPE OF FIREBOX
TYPE OF CONNECTIONS
IS BASED ON TYPE OF FIREBOX
LINE T4
NEUTRAL T5
NEUTRAL T6
NEUTRAL T7
HEATER T1
MOTOR T2
LINE IN
NEUTRAL
DISPLAY J8
J7 GESTURE
J5 FLAME 1W
J2 FLAME COLOUR
J3 TOP LIGHT
J4 TOP LIGHT
J1 LOG / MEDIA
F1400 MAIN BOARD 3001260100
NTC J11
FAN J10
FAN J9
HEATER ELEMENT
TOP LIGHT ASSY
FLAME LED ASSY
DISPLAY BOARD ASSY
TOP LIGHT ASSY
MOD -
MOD A
