Dimplex XHD23L Service Manual

1-888-346-7539 | www.dimplex.com
In keeping with our policy of continuous product improvement,
we reserve the right to make changes without notice.
© 2020 Glen Dimplex Americas
Light is leaking out around the log set
Log set is not positioned properly in
the unit
See instructions for replacing log set.
Ensure logset is connected to base
panel.
Heater
Heater is not turning on
Set temperature is below room tem-
perature
See operation instructions
Heat is disabled; --- is displayed when
heat button is pressed
See operation instructions
Defective heater assembly Replace heater assembly
Defective main control board Replace main control board
Heater cuts out after a short time
Inadequate air circulation
Ensure that there is su󰀩cient space
around the rebox. Install feet if nec-
essary.
Buildup of dust/debris
Ensure that the exterior intake louvers
and rebox cavity are free of dust/
debris
Defective heater assembly Replace heater assembly
Noise
Excessive noise when the heater is on
Buildup of dust/debris in the heater
assembly
Ensure that the exterior intake louvers
and rebox cavity are free of dust/
debris
Defective heater assembly Replace heater assembly
Excessive noise when ames are on
Flicker rod is hitting or rubbing against
internal component
Ensure that the icker rod is straight
and mounted properly in the bracket;
and spinning freely away from other
components. Replace the icker rod if
necessary.
Defective icker motor Replace icker motor
REV PCN DATE
01 - 29-AUG-19
02 - 23-DEC-19
03 - 6-OCT-20
