Page #15 background imageLoading...
Page #15 background image
15
M
AC / DC
120V / 12V
~
IR
REMOTE
M
L
LOGSET ASSEMBLY
FLAME BASE OR MEDIA BED RBG STRIP
FLAME LED LIGHTS
FLICKER
MOTOR
BLOWER
MOTOR
IR EYE/DISPLAY/CAPACITIVE
TOUCH CONTROL BOARD
MAIN CONTROL
BOARD
G
POWER
SUPPLY
NTC
CUTOUT
N
Electrical
