Error indicator readout
The LED readout screen displays fault codes that provide information about the
machine operating status and about malfunctions. The fault codes listed in the
following charts describe malfunctions and can aid in troubleshooting the machine
by pinpointing the area or component affected.
List of Fault Codes
Display
Description Lift Reaction
01 System Initialization Fault
Disables All Motion
02 System Communication Fault
Disables All Motion
03 Invalid Option Setting Fault
Disables All Motion
04 Calibration Fault
Warning Only
08 Key Switch Error
Disables All Motion
09 GPS Communication Fault
Warning Only
10 MC Communication Fault
Warning Only
11 BMS Communication Fault
Warning Only
12 Chassis Up or Down Switch ON
Disable Chassis Control
18 Pothole Guard Fault
Disable Lifting and Driving
31 31 Pressure Sensor Fault
Disables All Motion
32 32 Angle Sensor Fault
Disables All Motion
35 35 Pressure Sensor 2 Fault
Disables All Motion
36 36 Battery Drain Alarm
Drive speed limit
42 42 Platform Left Button ON
Warning Only
43 43 Platform Right Button ON
Warning Only
46 46 Platform Enable Button ON
Disable Platform Control
47 47 Joystick Not In Neutral
Drive speed limit
52 52 Drive Forward Coil Fault
Disable Lifting and Driving
53 53 Drive Reverse Coil Fault
Disable Lifting and Driving
54 54 Lift Up Coil Fault
Disable Lifting and Driving
55 55 Lift Down Coil Fault
Disable Lifting and Driving
