DINGLI JCPT0807HA - Page 64

OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
59
Display
Description Lift Reaction
56 56 Steer Right Coil Fault
Disable Lifting and Driving
57 57 Steer Left Coil Fault
Disable Lifting and Driving
59 59 Parallel Coil Fault
Disable Lifting and Driving
68 Battery Low Voltage Disables All Motion
80 Platform Load is over 80%
Warning Only
90 Platform Load is over 90%
Warning Only
99 Platform Load is over 99%
Warning Only
OL Platform Overloaded Disable All Motion
LL Machine Tiled
Disable Lifting and Driving
UP Platform up li mit position Warning Only
102 Restore Parameters to Default
Warning Only
103 Battery is draining
Warning Only
104 Motor Controller Fault
Warning Only
105 BMS Alarm Drive speed limit
106 BMS Fault Disable All Motion
PCU: n1,
ECU: 1xxx code
Left Drive Motor Controller Fault Controller Dependent
PCU:n2,
ECU: 2xxx code
Right Drive Motor Controller Fault Controller Dependent
PCU: n3,
ECU: 3xxx code
Pump Motor Controller Fault
Controller Dependent
PCU: n4,
ECU:4xxx code
BMS Fault
BMS Dependent
List of Fault Codes (motor controller)
Display
Description Lift Reaction
1008, 2008, 3008 WATCHDOG Controller Dependent
1017, 2017, 3017 LOGIC FAILURE #3 Controller Dependent
