DAG1000&2000SeriesFXOVoiceGatewayUserManual
35
Dinstar Technologies Co., Ltd.
Figure 4.9-1 port group configuration interface
Index
Port groupNumber, It uniquely identifies a route, range
from 0-15
Description
Port group description, its purpose is so you can identify
the port group with a meaningful name
Primary/Secondary Display Name
Port group display, which will be used in SIP message,
example:
INVITE sip:bob@biloxi.com SIP/2.0
Via:SIP/2.0/UDPpc33.atlanta.com;branch=z9hG4bK776as
dhds Max-Forwards: 70
To: Bob <sip:bob@biloxi.com>
From: Alice <sip:alice@atlanta.com>;tag=1928301774
Here Bob and Alice is the display
Primary/Secondary SIP User ID
User account information, provided by VoIP service
provider (ITSP). Usually in the form of digit similar to
phone number or actually a phone number.
Primary/Secondary Authenticate ID SIP service subscriber’s Authenticate ID used for
To Next Page
