Detecting Wear & Damage
Inspect slings, Cradle/Hanger bar and any pivot for slings prior to each use for signs of deterioration,
such as cracking or fraying. Replace worn parts immediately, and ensure the lift is not used until
repairs are made.
Cleaning the Sling & Lift
The sling should be cleaned regularly in water (do not exceed 180°F (82°C)) and a biocidal
(antibiological) solution. DO NOT use bleach when laundering the slings. Please refer to the sling
manual and/or product label for correct washing instructions. Clean the resident lift with a damp, soft
cloth and a small amount of mild detergent. Clean the lift with nonabrasive cleaners.
Boom Actuator Replacement
• CAUTION: DO NOT overtighten the nut
and bolt. Damage could occur.
a) Remove the nut, washer and shoulder
bolt that secure the electric actuator
to the mast mounting bracket.
b) Rest the boom on your shoulder and
remove the nut, bolt, plastic bushing
and pinch guard from the boom
mounting bracket.
c) Remove the boom actuator assembly.
d) Reverse steps for installation.
Mast Pivot Bolt
a) Check that the bolt is through the bracket and the locknut is tight and secure.
b) If needed, do one or more of the following:
Tighten locknut and back off the locknut
1
⁄8 of a turn.
Replace the locknut.
