Directed Electronics ProSecurity RK20 - Primary Harness (H1); 4-Pin Satellite Harness

16
© 2008 Directed Electronics. All rights reserved.
➤ Primary harness (H1)
H1/1
LIGHT GREEN/
BLACK
FACTORY ALARM DISARM
H1/2
GREEN/WHITE FACTORY ALARM DISARM
H1/3
YELLOW (+) IGNITION OUT (TO ALARM)
H1/4
WHITE/BLUE (-) ACTIVATION INPUT
H1/5
ORANGE (-) GROUND-WHEN-LOCKED
H1/6
BROWN (-) HORN OUTPUT
H1/7
RED/WHITE CHANNEL 2 (VALIDITY ONLY)
H1/8
BLACK GROUND
H1/9
WHITE (+/-) LIGHT FLASH
➤ Remote start harness, (H2) 5-pin connector
H3/1
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H3/2
VIOLET/WHITE TACHOMETER INPUT WIRE
H3/3
BROWN (+) BRAKE SHUTDOWN INPUT WIRE
H3/4
GRAY (-) HOOD PINSWITCH INPUT, ZONE 1
H3/5
BLUE/WHITE (-) 200 mA 2ND STATUS/REAR DEFOGGER OUTPUT
➤ 4-pin satellite harness
1
BLUE STATUS OUTPUT
2
ORANGE ACCESSORY TRIGGER
3
PURPLE STARTER TRIGGER
4
PINK IGNITION TRIGGER
