36
© 2008 Directed Electronics. All rights reserved.
Transmitter/receiver Learn Routine™
The system comes with transmitters that have been taught to the receiver. The
receiver can store up to 4 different transmitter codes in memory. Use the follow-
ing learn routine to add transmitters to the system.
The Program switch, plugged into the blue port, is used for programming. There
is a basic sequence to remember whenever programming this unit: Key, Choose,
Transmit and Release.
Insert the key. Turn the ignition to the ON 1.
position. The heavy gauge pink wire must be con-
nected.
Choose. Within 10 seconds, press and release the 2.
Program switch corresponding to the number of
the desired function step listed in the following table.
Once you have selected the function step, press the switch once more and hold
it. The LED flashes and the horn honks to confirm the selected functional step. Do
not release the Program switch.
