Directed Electronics ProSecurity RK20 - Heavy Gauge Relay 5-Pin Connector

24
© 2008 Directed Electronics. All rights reserved.
➤ Heavy gauge relay 5-pin connector
H/1
PINK (+) IGNITION OUTPUT
Connect this wire to the ignition wire in the vehicle. (See, Finding the wires
you need section in this guide.)
H/2
PURPLE (+) STARTER OUTPUT
Connect this wire to the starter wire in the vehicle. ( See, Finding the wires you
need.)
H/3
ORANGE (+) ACCESSORY OUTPUT
Connect this wire to the accessory wire in the vehicle that powers the climate
control system. (See, Finding the wires you need).
H/4
RED (2) (+) 12V INPUT FOR HIGH CURRENT OUTPUTS
H1/5
PINK/WHITE (+) OUTPUT TO A SECOND IGNITION/ACCESSORY CIRCUIT
Connect this wire to the second ignition/accessory wire in the vehicle. (See
menu 1 feature 6 for more information.)
Note: For vehicles that do not have a second ignition/accessory wire, this
connection is not required
H/6
RED (2) (+) 12V INPUT FOR HIGH CURRENT OUTPUTS
The heavy gauge wires coming from the large pin connector are used to ener-
gize the high current circuits in the vehicle. It is crucial to ensure that these con-
nections are capable of handling the current demands. For this reason, Scotch-
Locks, T-taps and other such connectors are strongly discouraged
