Directed Electronics ProSecurity RK20 - Heavy Gauge Relay Harness; Door Lock Harness, 3-Pin Connector

17
© 2008 Directed Electronics. All rights reserved.
➤ Heavy gauge relay harness
H/1
PINK (+) (30 AMP) OUTPUT TO IGNITION CIRCUIT
H/2
PURPLE (+) (30 AMP) OUTPUT TO STARTER CIRCUIT
H/3
ORANGE (+) (30 AMP) OUTPUT TO ACCESSORY CIRCUIT
H/4
RED (+) (30 AMP) HIGH CURRENT 12v INPUT
H/5
PINK/WHITE (+) PROGRAMMABLE OUTPUT FOR ACCESSORY OR IGNITION
RED (+) (30 AMP) HIGH CURRENT 12v INPUT
➤ Door lock harness, 3-pin connector
1
LIGHT BLUE (-) UNLOCK OUTPUT
2
EMPTY NOT USED
3
GREEN (-) LOCK OUTPUT
