© 2005 Directed Electronics—all rights reserved
33
wwhhaatt iiss iinncclluuddeedd
■
TThhee ccoonnttrrooll mmoodduullee ((sseeee ddiiaaggrraamm))
■
TThhee pplluugg--iinn pprrooggrraamm sswwiittcchh
■
AA hhoooodd ppiinnsswwiittcchh
■
AA ttooggggllee oovveerrrriiddee s
swwiittcchh
6-pin relay output
4-pin satellite/
harness
9-pin main harness
5-pin remote start
harness
not used
2-pin BLUE
program plug
status LED
