Directed DS4+ User Manual

27
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Lincoln MKS 2009-2012
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Factory Alarm Disarm Green/Violet 12 (-) DDM (Drivers Door Module) in drivers door. Gray 12 L
Parking Lights Violet/White 6 (+) Fuse/SJB (Smart Junction Box) under drivers dash. Gray 13 E
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut Fuse/SJB under drivers dash. Gray 26 D
Lock Gray/Yellow or Blue/
Green
17 (-) Fuse/SJB under drivers dash. Gray 26 D
Unlock Violet/Gray or
Yellow/Violet
4 (-) Fuse/SJB under drivers dash. Gray 26 D
Trunk/Hatch Release Gray/Yellow or
Brown/Yellow
20 (-) Fuse/SJB under drivers dash. Gray 26 D
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
1 (AC) Any fuel injector. Gray or
Black
2 N/A
Lincoln MKX 2008-2010
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
Power Liftgate Gray/Yellow 5 (-) Power liftgate switch. Black 6 I
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut Fuse/SJB (Smart Junction Box) under drivers dash. Gray 26 D
Lock Gray/Yellow 17 (-) Fuse/SJB under drivers dash. Gray 26 D
Unlock Violet/Gray 4 (-) Fuse/SJB under drivers dash. Gray 26 D
Factory Alarm Disarm Green/Violet 8 (-) Fuse/SJB under drivers dash. Gray 26 D
Parking Lights Violet/White 30 (+) Fuse/SJB under drivers dash. Black 32 D
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
1 (AC) Any fuel injector. Gray or
Black
2 N/A
