Directed DS4+ User Manual

28
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Lincoln MKZ 2008-2009
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
12V Blue/Red or Brown/
Red
4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Parking Lights Gray/Yellow 31 (+) Fuse/SJB (Smart Junction Box) under drivers dash. Brown 32 E
Driver Door Trigger Green/Violet 11 Cut Fuse/SJB under drivers dash. Black 32 D
Lock Gray/Yellow or Blue/
Green
4 (-) Fuse/SJB under drivers dash. Black 32 D
Unlock Violet/Gray or
Yellow/Violet
10 (-) Fuse/SJB under drivers dash. Black 32 D
Factory Alarm Disarm Violet/Brown 5 (-) Fuse/SJB under drivers dash. Black 32 D
Trunk/Hatch Release Brown 27 (-) Fuse/SJB under drivers dash. Black 32 D
Tach NOT white/blue
(2.3L, 3.0L), NOT
violet/grn (3.5L)
N/A (AC) Any fuel injector. N/A N/A N/A
Mercury Mariner 2008-2011
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB (Smart Junction Box) passenger side of the center console. Gray 26 F
Trunk/Hatch Release Brown 7 (+) SJB passenger side of the center console. Gray 26 F
Lock Blue/Green 17 (-) SJB passenger side of the center console. Gray 26 F
Unlock Yellow/Violet 4 (-) SJB passenger side of the center console. Gray 26 F
Parking Lights Violet/White 20 (+) SJB passenger side of the center console. Black 32 G
Factory Alarm Disarm Violet/Brown N/A (-) Drivers kick panel, door harness. N/A N/A H
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
N/A (AC) Any fuel injector. N/A N/A N/A
