16
933.HONDA9 2.10.198.12 2022 Honda HR-V (Smart Key)
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with T-Harness (THHON1 Rev. 1 & 2) without Vehicle Takeover
THHON1 Rev. 1 & 2 (Optional T-Harness)
(-) Parking Lights: Lt. Blue/Black
Siren
Hood Pin
(-) Hood Input: Gray
(+) Siren Output: Brown/Red
Refer to the Optional starter
disable connection section for
relay and connection details.
(-) GWA Output: Red/White
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
22-pin White Connector
12-pin Black Connector
8-pin White Connector
22 812
4 2442
Slide to open
A module can also be used for
this installation.
IMPORTANT:
Position the
fuses correctly!
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT (15A) (+)
5
5
30
20
20
Keyless Access Control Unit
(gray 20-pin connector)
Keyless Access Control Unit
(gray 36-pin connector)
(-) Parking Lights:
Gray, pin 8
Headlight Switch
(white connector)
123456
711
8
91012
1
1
2
2
Keyless Acces Control Unit
(behind instrument cluster)
