Directed VOXX DEI DS3+ - Page 20

20
933.HONDA9 2.10.198.12 2022 Honda HR-V (Smart Key)
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/9 Dk. Blue/Black (MUX) Takeover 2 Output - Required for installations
WITH vehicle takeover ONLY.
Must use (2) 8616 mini relays.
Must use (2) 1N4002 diode or larger.
5A fuse to 12V.
Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 34
Cut White
Remote Start
Only
H2/10 Lt. Blue/Black (-) Parking Light Output Headlight Switch, white 12 pin plug, pin 8 - Gray
Mandatory
H2/11 Brown/Red
(+) Siren Output [2]
Security Only
H2/12 Pink (+) Ignition Sense Input No Connection
H2/13 Violet (+) Door Trigger Input No Connection
H2/14 Brown (+) Brake Input No Connection
H2/15 White/Blue (-) Activation Input No Connection
H2/16 Red/Blue (-) Headlight Detection Input No Connection
H2/17 Black/White (-) E-Brake Input No Connection
H2/18 Orange/Black (+) Instant Trigger Input No Connection
H2/19 Blue (-) Trunk Trigger Input No Connection
H2/20 Green (-) Door Trigger Input No Connection
H2/21 Gray
(-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input No Connection
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White
Relay N.C. - Ignition Interrupt (vehicle side) [3]
Required for installations WITH vehicle takeover ONLY.
Steering Lock Module under steering column, gray 12 pin plug, pin 12
Required for installations WITHOUT vehicle takeover ONLY.
Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 34
Cut
Cut
White (if equipped)
White
Remote Start
Only
H3/2 Blue/Red Relay N.O. - No Connection No Connection
H3/3 Blue
Relay COM - Ignition Interrupt (conn. side) [3]
Required for installations WITH vehicle takeover ONLY.
Steering Lock Module under steering column, gray 12 pin plug, pin 12
Required for installations WITHOUT vehicle takeover ONLY.
Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 34
Cut
Cut
White (if equipped)
White
Remote Start
Only
H3/4 White/Brown Relay N.C. - (+) Accessory Interrupt 1 (connector
side)
No Connection
H3/5 White Relay COM - (+) Accessory Output Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 16
+ Gray
Mandatory
H3/6 Red (+) 12 Volt Input Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 18
+ Red (10A)
Mandatory
H3/7 Lt. Green/Red Relay N.O. - (+) 12 Volt Input Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 18
+ Red (10A)
Remote Start
Only
