Directed VOXX DEI DS3+ - Page 21

21
933.HONDA9 2.10.198.12 2022 Honda HR-V (Smart Key)
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/8 Lt. Green Relay COM - (+) Ignition Output/Interrupt (vehicle
side)
Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 17
+ Pink
Mandatory
H3/9 Lt. Green/White Relay N.C. - Ignition Interrupt (conn. side) Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 17
Required for installations WITH vehicle takeover ONLY.
+ Pink
Remote Start
Only
H3/10 Black (-) Ground (chassis ground)
Mandatory
H3/11 White Relay COM - (+) Accessory Output Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 16
+ Gray
Remote Start
Only
H3/12 Red (+) 12 Volt Input Keyless Access Control Unit behind instrument cluster, gray 36 pin plug,
pin 18
+ Red (10A)
Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black (+) 12 Volt Input No Connection
H4/3 Pink/Black Flex Relay (pin 87a) No Connection
H4/4 Pink/White (+) Flex Relay Output No Connection
H4/5 Red (+) 12 Volt Input No Connection
H4/6 Green Starter Input (conn. side) No Connection
H4/7 Violet (+) Starter Output (vehicle side) No Connection
H4/8 Orange (+) Accessory Output No Connection
H4/9 Red/White (+) 12 Volt Input No Connection
H4/10 Pink (+) Ignition Input/Output No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
