Appendix D - Remote Protocols
Remote Protocol D - SSL
ANDIAMO.MC supports SSL’s ‘Remote Gain over MADI’ control, allowing full
control for the 32 input channels of:
• input gain
• phantom power
• PAD in/out status
The unit can be used with C10, 100, & 200 and will provide 32 Mic/Line inputs and
32 Line outputs. The unit supports full redundant operation when connected to
Master and Slave Blackrock processors and is is fitted with dual phase redundant
power supplies.
With C10 and C100, the MADI port connected to the unit should be configured as
MADI RMTE with the ‘Number of Mics’ set to 32.
NOTE
Although MADI channels 33-64 will show up in the I/O lists they will not carry any
signal and should not be included in any I/O groups.
With C200, use the standard DHD Stagebox configuration page with 8 Mic amp
modules in the first 8 slots starting form the left, and 8 Line output modules in the
corresponding lower slots.
The ANDIAMO.MC supports 2 FS S/MUX mode for higher sample rate operation
with C200.
