ANDIAMO.MC Hardware Guide - Version 2.0
CHAPTER 1: Overview
Feature Summary
MADI Ports 2 x SC-Socket multi/single-mode (SC/SC)
or
1 x SC-Socket multi/single-mode &
1 x coaxial BNC connector, 75 Ω (BNC/SC)
MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4
Mic / Line Inputs 32 channels, balanced via DSUB-25,
AES59 compliant
phantom power switchable (+ 48 V)
PAD switchable (30 dB)
Line Outputs 32 channels, balanced via DSUB-25,
AES59 compliant
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz ±12.5%
Clock Inputs 1 x Word clock, coaxial BNC,
75 Ω termination switchable,
This input also accepts an AES3 frame (AES11).
Clock Outputs 1 x Word clock, coaxial BNC
GPO 2 x MOSFET switch
USB Port USB 2.0 port for firmware updates and remote
control
Routing Matrix Signal routing on a per channel basis
160x160 routing matrix.
Remote Control Software Remote control via USB, Serial over MADI,
MIDI over MADI or DO.Net
support of particular 3rd party protocols:
Yamaha, SSL, Avid PRE, Eucon, Lawo Dallis
Power Supply This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety
class 1)
Applications
ANDIAMO.MC can be used for conversion, amplification, monitoring and recording
of analog and digital signals.
Typical applications include:
• recording mic / line signals (32 inputs)
• redundant recording using both MADI I/Os
• 1:2 splitting of analog input signals (input to MADI & D/A line out)
• monitoring a MADI signal (32 line outputs)
• signal distribution (routing matrix)
• format conversion of MADI signals
• ...
