page 25 of 60EXBOX.MD Manual - Version 1.0
Chapter 3: Installation
The connected power supply must provide a current
limiting to a maximum of 2.5 A.
Keep any packaging in order to protect the device
should it need to be dispatched for service.
Never connect a PoE link to a network interface that
is not marked explictly for PoE operation. The voltage
supplied there may damage the interface.
WARNING
Power over Ethernet
The device can also be operated via a power over
ethernet connection. Connect the port labelled '01
(PoE)' to an appropriate PoE switch (PoE Class 0 /
0.4 - 13 W).
WARNING
TIP
