disperator 515A - Page 33

User manual in Original
Doc. ref: 500A_MC_am_en_210602
DISPERATOR AB Tel: 08-724 0160 E-mail: info@disperator.se
Mälarvägen 9, 141 71 Segeltorp Web page: www.disperator.se
33 / 44
32 / 44
Posion No: Qty: Denominaon: Spare Part No: Included in
Service Package:
P1 1 Motor with drained upper ange -14
P2 1 Carrier -18 2
P3 1 End shield -13
P4 1 Washer for V-ring seal -03/00 1 and 2
P5 2 Axle seal, with stainless spring -03/02 1 and 2
P6 1 Locking ring -03/03 1 and 2
P7 4 Screw for end shield assembly -23 1 and 2
P8 1 V-ring seal -03/01 1 and 2
P9 1 Key for carrier -10 1 and 2
P10 1 Rotary shredder -02 2
P11 1 Axle washer -06 2
P12 1 Axle screw -07 1 and 2
P13 1 Staonary shredder -01 2
P14 1 Seal for staonary shredder -05 1 and 2
P15 1 Hood -16
P16 4 Locking nut and washer for hood assembly -25 1 and 2
P17 1 Seal for hood ange -08 1 and 2
P18 6 Screw and nut for disposer assembly -22 1 and 2
Below parts with Pos. No. P19 – P25 are not used for disposers installed in closed cabinet models
P19 1 Strap for housing -17
P20 1 Housing -15
P21 1 Sealing list for housing -15/01
P22 1 Cable gland with nut -19
P23 2 Screw and washer for housing assembly -26 1 and 2
P24 3 Adjustable disposer leg (only for Model 520, 530, 550 and 575) -29
P25 3 Screw for disposer leg -29/01 1 and 2
Not depicted parts
P26 1 Special grease for seals and carrier -04 1 and 2
P27 1 Rubber sealing compound -09 1 and 2
P28 2 Axle seal, motor drive end and motor non-drive end -14/01
P29 2 Bearing, motor drive end and motor non-drive end -14/02
P30 1 Key for motor sha -14/03
P31 1 Disassembly screw for carrier -18/02 2
