Parts depicted on the next pages
P17 1 Noise damping seal (alternave to spare part No. -08) -08/1
P32 1 Torque protecon bracket for xaon of disposer in wall/bulkhead -28/V
P33 1 Jam release wrench for rotary shredder -31
P34 1 Solenoid valve, G½” (BSPP), internal thread, incl. coil, cable plug and
xang washer
-35
P35 1 Coil for solenoid valve -36
P36 1 Line strainer, G½” (BSPP), internal thread -37
P37 1 Start & stop unit incl. contactor with motor overload protector -38
P38 1 Contactor with coil -38/1
P39 1 Start contact -38/2
P40 1 Motor overload protector -38/3
P41 1 Safety Interlock Switch -39
P42 1 Seal to interlock switch -39/01
P43 1 Key for Safety Interlock Switch -39/03
Always state machine serial number and spare part number (see above) when ordering spare parts.
NOTE! That the correct quality and strength of all nuts and screws used are important. Disperator can not guarantee the safety
if other screws and nuts than those ordered from us are used.
