10. Pry the staonary shredder (P13) loose from the end shield (P3) using a crowbar that levers
against the large tooth on the inside edge and is supported by the rotary shredder (P10) close to
one of the two shredder blades. See photo below.
11. Loosen the axle screw (P12). If the rotang shredder (P10) keeps turning, and cannot be held
sll manually, use a pipe wrench to hold one of its shredder blades. Alternavely, lock the rotary
shredder with a screwdriver placed through one of the holes at the disposer outlet (see photo
below).
12. Remove the rotary shredder (P10) by placing two crowbars opposite one another under the edge
of the shredder, supported by the side of the end shield (P3). See photo below.
13. Remove the V-ring seal (P8) and loosen the 4 xing screws (P7) of the end shield (P3). Note the
posion of the outlet on the end shield (P3) relave to the terminal box for cable connecon
on the motor (P1), so that this outlet will receive the same direcon when reassembling the
disposer. Remove the end shield.
14. Inspect the washer (P4) for possible wear caused by the V-ring seal. Replace the washer if
necessary.
15. Turn the end shield (P3) upside down and remove the locking ring (P6) by means of a circlip
pliers. See photo below. With some adequate protecon in between (e.g. a piece of wood as in
the below photo), apply pressure to the washer (P4) in order to get the two axle seals (P5) out.
Aer this dismantling make sure that the surface of the sealing washer (P4) remains in good
condion.
