Cx Series Operator’s Manual Specifications - 113
C24x
Operation US Metric
Vehicle speeds
Max transit forward 176fpm 53.6m/min
Max transit reverse 136fpm 41.5m/min
Digging chain speed
19K 366fpm 111.6m/min
35K 309fpm 94.2m/min
Spoils handling, Single, open-end auger
Outer diameter 17” 432mm
Max operating weight 1915lb 869kg
Engine US Metric
Engine: Honda® GX690
Fuel gasoline
Cooling medium air
Number of cylinders 2
Displacement
42in
3
688cm³
Bore 3.07” 78mm
Stroke 2.83” 72mm
Manufacturer’s net power rating @3600rpm (per SAE J1940) 22.1hp 16.5kW
Rated speed 3600rpm 3600rpm
Fuel consumption 1.77gph 6.7L/h
Max tilt angle* 20° 20°
* Exceeding these operational angles will cause engine damage. This DOES NOT IMPLY machine is stable to maximum angle of
safe engine operation.
Battery
310 CA, 12V, reserve capacity 30 min
