Cx Series Operator’s Manual Overview - 5
Operator Orientation
Operator Orientation
1. Front
2. Right side
3. Rear
4. Left side
Operating Area
Operator should stand only in the location
shown.
IMPORTANT: Top view of machine is shown.
IMPORTANT: Top view of machine is shown.
